Discover the new version of the micro:bit card! More power and features thanks to the integrated sensors (microphone, speaker, bluetooth antenna, touch logo).

This new version of the card also allows the activation of an "energy saving" mode.

• Based on a nRF52833 microcontroller, the card is powered via a micro-USB port, JST connector or the 3V and GND pins
• Number of inputs / outputs: 23 pins including 6 analog inputs
• The card has :
• a matrix 5x5 red LEDs
• 2 push buttons
• microphone
• speaker
• touch logo
• bluetooth antenna
• Bluetooth 5.1
• 2.4 GHz radio interface (not WiFi compatible)
• 6-axis accelerometer/gyroscope
• Clock speed: 64 MHz
• RAM memory: 128 kB
• Speaker: 80 dB at 5 VDC
• Available output current: 200 mA
• Size of the card: 40 mm x 50 mm
• Weight: 8g

Comes with 2 batteries, a battery connector and a micro-USB cable.

Manufacturer : BBC Micro:bit

Reference : MBV2
